For Climbing
- Builds physical coordination
- Encourages problem solving
- Fun for individuals and groups


01 / Product hero
2 Level Adventure Cube Playground (model DG-AC-202) has a recommended floor area of ≈861.11 ft² (80 m²) and a target age range of 0–12 years. Qualification: ASTM F1918-21 / EN 1176-1; pricing is quoted for the agreed configuration and supply scope.
Model: DG-AC-202
| Customization | Customization on request |
|---|---|
| Product type | Indoor Playgrounds Equipment |
| Age range | 0–12 years |
| Floor area | ≈861.11 ft² (80 m²) |
| Theme | Ocean & Underwater |
| Qualification | ASTM F1918-21 / EN 1176-1 |
02 / Product overview
Designed for shopping malls, FEC units and play cafés that need high play density in under 1,000 sq.ft. with clear caregiver sightlines.
Modules wrap real building columns instead of forcing a catalog footprint.
Core modules: 2-deck steel frame, twin wave slides, crawl tunnel, net ramp, bubble pod, toddler soft bay, ball pool, padding and knotless netting.
Recommended applications: Family Entertainment Centers · Shopping Malls & Retail · Play Cafés & Restaurants
03 / Play features
Explore the activities in this reference configuration and discuss the right mix for your target ages.








04 / Specifications
| HS Code | 950699 |
|---|---|
| Category | Indoor Playgrounds Equipment |
| Design Theme | Ocean & Underwater |
| Application Venue | Family Entertainment Centers · Shopping Malls & Retail · Play Cafés & Restaurants |
| Required Clear Height | 3.8–4.2 m |
| Age Range | 0–12 years |
| Features | For Climbing · With Slide · Ball Pool · Crawl Tunnels · Sensory Play · Soft Blocks · Toddler Zone · Net Play |
| Minimum Age | 2 years |
| Height | 14 ft (4.27 m) |
| Qualification | ASTM F1918-21 / EN 1176-1; ASTM F1918-21 · Soft contained play equipment · Applies to the listed DG-AC-202 configuration scope agreed in the contract.; EN 1176-1 / 1176-10 · Fully enclosed play equipment · Material and entrapment testing per agreed BOM.; CSA Z614-20 · Children's playspaces and equipment · Confirm applicable edition and model scope in proposal.; ASTM F1918-21, CSA Z614-20, EN 1176-1/10 (project scope) |
| Suggested capacity | 10–50 children (peak) |
| Age note | Dual-zoned layout |
| Packing volume | ≈42 m³ (reference DG-AC-202 packing list) |
| Container loading | 1 × 40HQ typical (confirm after loading plan) |
| Commercial warranty | 18-month commercial warranty (terms per contract) |
| Model & series | DG-AC-202 (Adventure Cube commercial soft play) |
| Equipment dimensions (L × W × H) | 10.0m × 8.0m × 4.0m clear (≈80 m² / 860 sq.ft.) |
| Structural frame | Φ48mm hot-dip galvanized steel, powder coated |
| Soft cladding | 0.55 mm B1 PVC over 20 mm EPE foam |
| Ball pool | 8,000+ commercial PE balls (70 mm), crush-resistant |
| Warranty | 18-month commercial warranty (terms per contract) |
| Installation support | Confirm installation scope in project proposal |
| Customization | Customization on request |
Reference dimensions describe the equipment. Allow for installation, activity zones and circulation; final requirements follow the approved layout.
05 / Customization options
Every playground is unique. We customize layouts, themes, colors, and play features to match your space, target age group, and budget.

Adapt the footprint, deck heights, columns and entrances to the measured venue.

Review palettes, graphics and brand elements alongside the layout.

Choose the activity mix for your target ages, capacity and operating plan.

Compare module counts, finishes and delivery scope against your budget range.
06 / Design & manufacturing
One team takes your project from floor plan to handover.
Share your floor plan, clear heights, location, target users and budget. Review site constraints and local responsibilities before design begins.
Review the layout, 3D concept, equipment specification and itemized quotation. Confirm the scope, drawings and installation option before production.
Manufacture the approved equipment in our factory, with agreed quality checks, progress records and trial assembly before packing.
Protect and label components, prepare packing lists and export documents, and coordinate transport under the agreed shipping terms.
Assemble and check the supplied equipment using the agreed installation crew, on-site supervisor or remote engineering guidance.
Record handover checks, provide care instructions and support opening preparations, with ongoing technical assistance and matching spare parts.
07 / Real-World Installations
Explore real-world playground installations delivered and operating in family entertainment centers, shopping malls, and adventure parks worldwide.

Design and layout reference for a shopping mall play zone in Bohol, Philippines. Approximately 950 m² is a reference design area, not a measured as-built area.

Indoor active recreation and trampoline venue layout in Melbourne combining interconnected jump courts, angled walls and padded walkways.
ChileMulti-zone shopping mall family entertainment center in Santiago, Chile combining a multi-level soft play structure, jump courts and feature slides.

Jungle-themed indoor family play configuration in Libya combining soft play structures, wave slides, trampoline zones and toddler play.
The client perspective
Customer feedback from our Google Business Profile, covering equipment quality, design and project support.
Loading reviews connects your browser to Elfsight and Google.
08 / FAQs & Project Inquiry
Have questions about venue fit, customization, certifications, or delivery? Review common answers or submit your floor plan for an engineering review and itemized quote.
Need immediate engineering advice?WhatsApp ConsultationEmail Us

Share your venue dimensions, target ages and budget so we can review a layout and quotation within 24 hours.
We respect your privacy. Your information will only be used for project communication.
Plan for 3.8–4.2 m (12.5–13.8 ft) clear to the lowest beam, duct or sprinkler. We confirm deck heights and slide run-outs against your as-built survey.
Yes. The modular cube grid scales from about 40 m² to 150+ m². Send a sketch or CAD plan for a layout matched to your columns and exits.
It is a reference FOB figure for model DG-AC-202. Final pricing depends on finishes, shipping terms, installation scope and destination requirements.
